Description
Specification
Engine: 1E39F
Engine type: Air cooling single cylinder,2 stroke
Rated output power: 1.6kw/8500rpm
Displacement: 38CC
Idling speed: 3000r/min
Igniton system: C.D.I.
Lubrication system:Crankcase Pressure-driven
Air cleaner: Semi-dry
Gasline/two-stroke FC oil mixing ratio: 50:1
Fuel tank capacity: 310ml
Oil tank capacity: 210ml
Guide bar: 12’’(30cm)/14’’(35cm)/16’’(40cm）
Saw chain: 3/8’’/0.325’’
G.W./N.W.: 6.5/5.5kgs
Packing Size: 50x25.5x29cm/ color box
Appltcatton
FAQ
